The Splendide® ARWXF129W Compact Washer - What to Know

The Splendide® ARWXF129W Compact Washer - What to Know

The Splendide® ARWXF129W is a compact washer designed for efficient laundry care in limited spaces. To ensure optimal performance and longevity, it's important to understand its features and follow proper maintenance procedures. Based on the official Splendide® documentation, here's an overview of the ARWXF129W washer:

Key Features

  • Compact Design: Ideal for installations where space is limited, such as RVs, boats, or small apartments

  • Multiple Wash Cycles: Offers various wash programs to accommodate different fabric types and laundry needs.

  • Energy Efficiency: Designed to consume less water and energy, making it an eco-friendly choice.

Installation and Setup

Proper installation is crucial for the washer's performance:

  1. Unpacking:

    • Remove the washer from its packaging and inspect for any transportation damages. If damaged, contact the retailer before proceeding

    • Remove the four protective screws and the rubber washer with the corresponding spacer from the rear of the appliance.

    • Close the holes with the provided plastic plugs

    • Keep all removed parts for potential future relocation of the washer.

  2. Levelling:

    • Place the washer on a flat, sturdy floor, ensuring it's not against walls or furniture.

    • Adjust the front feet to level the washer, keeping the angle of inclination within 2° to prevent vibrations and noise.

  3. Connecting Water Inlet:

    • Use the provided cold water fill hose to connect to the cold water supply.

    • Ensure the water supply faucets are easily accessible

  4. Drainage:

    • Connect the drain hose to a standpipe with a minimum diameter of 1¼” and a minimum carry-away capacity of 7 gallons per minute.

    • The standpipe's top should be between 25” and 34” from the washer's bottom

For detailed installation instructions, refer to the official manual.

Operating Instructions

To operate the ARWXF129W washer:

  1. Loading:

    • Open the door and load your laundry, ensuring not to exceed the washer's capacity.

  2. Detergent Dispensing:

    • Use only low-sudsing detergents suitable for front-loading washers.

    • Add detergent to the dispenser drawer, following the manufacturer's guidelines.

  3. Selecting a Wash Cycle:

    • Turn the cycle selector knob to choose the appropriate wash program for your load.

  4. Starting the Wash:

    • Close the door securely.

    • Press the "ON/OFF" button to power on the washer.

    • Press the "START" button to begin the selected wash cycle.

For detailed operating instructions, refer to the official manual.

Winterization Instructions

If you're using the washer in RV or marine environments, it's essential to winterize it to prevent damage from freezing temperatures:

  1. Antifreeze Application:

    • With the washer powered off, pour ½ quart of RV-type antifreeze into the drum.

    • Close the door, set the cycle selector to position 'B', press "ON/OFF", then press "START". Let the washer run for 1 to 2 minutes

    • Press "ON/OFF" to turn off the washer.

  2. Disconnecting Water Supply:

    • Turn off the water supply faucets

    • Disconnect the inlet hoses from the faucets and drain any remaining water

For comprehensive winterization steps, refer to the official winterization instructions.

Maintenance Tips

  • Regular Cleaning: Periodically clean the drum, door seal, and detergent dispenser to prevent mold and detergent buildup.

  • Check Hoses: Inspect water inlet and drain hoses for leaks or blockages.

  • Leveling: Ensure the washer remains level to minimize vibrations and noise.

For more detailed information, troubleshooting, and service support, visit the Splendide Laundry Centers Support Center.

Note: Always refer to the official Splendide® documentation for the most accurate and up-to-date information.
